IEEE 841 Motor Three Phase Motor Design 3-Phase 100 HP Nameplate RPM 3 600 No of Speeds 1 Voltage 460V AC Full Load Amps 110.0 A 404/5TS Frame Usable @ 208V No Usable @ 200V No Hz 60 Hz Motor Service Factor 1.25 Max Ambient Temp 104 Degrees F Motor Thermal Protection None Duty Cycle Continuous Ins. Class F NEMA Design B Motor Enclosure Design Totally Enclosed Fan-Cooled Motor Shaft Rotation CW/CCW Motor Mounting Type Rigid Base Motor Mounting Position Horizontal
