Speed Reducer Input Connection Type C-Face Gear Type Worm Output Shaft Type Round Maximum Output Speed 175 RPM Motor Frame Designation 210TC/250UC Worm Center Distance 3.75 in Base to Center 3.88 in Gear Ratio 10 1 Rotation CW/CCW Maximum Input Horsepower 8.4 hp Maximum Output Torque 2834 in-lb Overhung Load Capacity 2 000 ft-lb Mounting Orientation Any Angle Housing Material Cast Iron Bearing Type Tapered Roller Gear Material Hardened and Ground Steel
